-35 -

REF.

NO.

PART
NUMBER

DESCRIPTION

QTY.

1

731-3212

Cup Holder

1

2

631-3002

Cover, Implement Lift

1

3

703-2278B Fender 1

4

710-0751

Screw, Hex Cap, 1/4-20 x .62 GR5

6

5

710-1260A Screw, Hex Wash Hd Tapp 5/16-18 x .750

6

6

710-1268

Screw, Hex Tapp, #10 x .38 Lg

2

7

712-3027

Nut, Hex Flange Lock, 1/4-20

6

8

723-3042

Bushing, Snap, 7/8 ID

1

9

726-0211

U-Nut, 5/16-18

6

10

732-3122

Retainer, Hook

2

11

735-3046A Pad, RH Foot

1

12

735-3047

Pad, LH Foot

1

13

703-2279
777S30170
777D04382

Running Board w/Graphic

Graphic, Warning
Graphic, Shaft Drive

1
1
1

14

777D04791 Graphic, Rear Fender

1

15

703-2628

Bracket, Fender Reinforcement

2

16

710-0224

Screw, Hex Tapp, #10-16 x .5 Lg.

4

FENDER AND RUNNING BOARD
