Hydro transmission – Cub Cadet 2186 User Manual
Page 11
-11 -
REF.
NO.
PART
NUMBER
DESCRIPTION
QTY.
1
618-0579A
Hub Assembly, Wheel
2
2
618-3060
Plate Assembly, Brake
1
3
618-3084
Shift Yoke Assembly
1
4
619-0056
Axle Housing, RH
1
5
619-0057
Axle Housing, LH
1
6
719-3171
759-3746
Transmission Housing, RH
Sealant, Ultra Grey
1
7
719-3170
Transmission Housing, LH
1
8
703-2191
Brake Arm
1
9
710-0606
Screw, Hex Cap, 1/4-20 x 1.5
2
10
710-0788
Screw, Hex Wash Hd Tap, 1/4-20 x 1.0 13
11
721-3029
Seal, Shift Shaft
1
12
710-1008
Screw, TT, 3/8-16 x 1.875
16
13
710-1346
Screw, Plug, M14 x 1.5 x .827
1
14
710-1670
Screw, Hex Hd Cap, 3/8-24 x 2.0 GR5
4
15
710-3262
Screw, Cap, 3/8-16 x .750
1
16
711-1052A
Shaft, Cross, .500 x 3.005
2
17
711-1320
Shaft, Axle, 1.00 x 12.90
1
18
711-1566
Shaft, Axle, 1.00 x 16.62
1
19
711-3374
Shaft, Drive
1
20
711-3379A
Shaft, Shifter
1
21
712-0291
Nut, Hex Center Lock, 1/4-20
2
22
712-1329
Nut, Hex, 3/4-16
2
23
715-3045
Dowel Bushing
6
24
716-0172
Ring, Retaining, .750
4
25
716-0204
Ring, Retaining,
2
26
717-1446
Gear, Miter, 10T
4
27
717-1447
Gear, Miter, 14T
2
28
717-1568
Gear, Differential Spur, 60T
1
29
717-3346
Shaft, Output, 9T
1
30
717-3347
Gear, Bevel, 36T
1
31
717-3387
Gear, Spur, 18T
1
32
717-3388
Gear, Spur, 27T
1
33
717-3391
Gear, Spur, 16T
1
34
717-3392
Gear, Spur, 42T
1
35
718-3039
Collar, Drive
1
36
719-0375
Housing, Differential, RH
1
37
719-0378
Housing, Differential, LH
1
38
721-0520
Seal, Oil, 25.4mm x 54mm x 7mm
2
39
721-3008
O-Ring, 3/8 ID x 1/2 OD x 1/16 Thk
1
40
727-3085
Dipsick, Oil
1
41
732-0152
Spring, Compression
1
42
732-3077
Spring, Brake Shoe
1
43
732-3113
Spring, Compression, 1.015 ID x 1.6
1
44
736-0600
Washer, Flat, .558 x .866 x .078 Thk
1
45
736-0463
Washer, Flat, .25 x .630 x .0515
4
46
741-0361
Bearing, Ball, 17 ID x 40 OD x 12
4
47
741-3057
Bearing, Ball, 6204
2
48
741-3114
Bearing, Ball, 6205-1
4
49
750-3133
Spacer, .757 x 1.0 x 1.460
1
50
750-3134
Spacer, .885 x 1.125 x 1.40
1
51
761-3019
Drum, Brake
1
52
761-3020
Brake, Shoe
2
53
761-3028
Brake, Actuator
1
54
736-0745
Washer, Flat, 1.010 x .56 x .060
2
REF.
NO.
PART
NUMBER
DESCRIPTION
QTY.
HYDRO TRANSMISSION
