breaking load limit and the maximum

safe working load limit (SWLL). In this case, the
breaking load limit of each of the flying points is
4,000 kg (8,820 lbs) as determined by destructive
testing in independent laboratories. With a 10:1
safety factor, a total amount of 1,600 kg (3,527
lbs) can be flown from the 4 flying points. Each
flying point has a capacity of 400 kg (882 lbs) with
a 10:1 safety factor.

The safety factor is defined as the coefficient

between the

Each of the flying point have a load of 400Kg

(882lbs) with a 10:1 safety factor.

T

The use of two hoists with a load capacity as

expressed on the previous page is mandatory. It
should be kept in mind that at certain moments,
the complete load may be supported by only one
of the hoists.

he maximum number of

units that

can be suspended from the

flying grid

is 20 (with 10:1 safety factor). The maximum
number of

units that can be suspended

from the

flying grid is 16 (10:1). The

maximum limits established by the manufacturer
should never be exceeded.

This is why the load capacity of the

individual hoist must be superior to the weight of
the array column.

NOTE: The rigging systems of the

,

and the

are compatible. Some accessories

(

,

) can be used by both

systems.

AX-AERO48

AX-AERO48

AX-AERO38 AX-AERO48

aero 38A

LX-218RA

aero38 aero38A

aero 48

4 x 400Kg (10:1)

Safety factors

EN

14

Rigging systems for

and

.

aero 38A

LX-218RA

Manual del Usuario

/ aero 38A & LX-218RA / User’s Manual
