>750Kg
1-->8 units
aer
o
38A
>750Kg
1-->6 units
LX-218RA
AX-AERO38
LX-218RA
AX-AERO48
>1000Kg
>2000Kg
>750Kg
>1500Kg
1-->10 units
1-->8 units
11-->20 units
9-->16 units
aer
o
38A
G2A48
G1A48
QUICK RELEASE PIN 8X30
(6 UNITS PER CABINET)
To aid the setting of the G2A48 guide in the
corresponding hole in the top box, each hole is
labeled with an associated angle, both for stacked
and flown applications. To fit the guides into the
holes, highly resistant 8 mm quick release pins
with a ball safety lock are used.
For flying boxes and defining the splay angle,
the pins must be inserted in the slot of guide 2,
G2A48, whereas for stacking (stacked), the pin
goes through the top hole of the guide:
STACK FLY
B) Chain hoist
All units in a column will be flown from the
( ) flying grid (bumper bar),
which should be used with two hoists, one located
in the front and the other in the rear. Each hoist
should have a minimum of 1 Ton load capacity
when flying up 8 units and a 2 Ton load capacity
when flying 9 to 16 units.
AX-
AERO48 AX-AERO38
A) Y AX-AERO48 AX-AERO38
The grid is made from 100 x 50 x
6mm steel beams and is designed to handle great
loads. It features a center reinforcement bar that is
also used for the lifting slings. The force of both
the rear and the front chain hoist will determine the
tilt angle of the whole array. The structure will be
attached to the first enclosure of the array by
means of the guides G1A48, G2A48, and six quick
release safety pins.
AX-AERO48
All of the elements needed to rig or stack the
systems are integral to the enclosure (
and the quick release safety pins). The
additional items needed are the or
flying grids (bumper bars), chains and
hoists, the or dolly platforms and the
flying grid.
AX-AERO48 AX-
AERO38
PL-38 PL-48S
AX-COMBO
G1A48,
G2A48
4.8º
6.4º
8º
9.6º
3.2º
1.6º
0º
0.8º
STACK
4.8º
6.4º
8º
9.6º
3.2º
1.6º
0º
0.8º
2.4º
FLY
Splay angles
Pickup points
Weight:
Dimensions: 147x62x10 cm
(H x W x D)
60Kg (132 lbs)
57.8x24.4x4 in
The grid is lighter than the other
one, and it is recommended to be used to fly a
maximum of 8 units
or 6 units .
AX-AERO38
aero38A LX-218RA
Weight
Dimensions: 144x93x10 cm
(H x W x D)
: 75Kg (165 lbs)
57x36.6x4 in
Load capacity per hoist
(safety factor 10:1)
For example, if 12 units , are going to
be flown from the , each hoist to be
used should have a load capacity of 2 ton.
LX-218RA
AX-AERO48
EN
