Rocket Port Interface Box DB25 Signals
DB25 Pin
RS232 Signal
RS422 Signal
(RocketPort
RS232/422
version only)
Universal Interface
2
TxD
*See note
See UI manual
3
RxD
*See note
See UI manual
4
RTS
*See note
See UI manual
5
CTS
*See note
See UI manual
6
DSR
*See note
See UI manual
7
Signal Gnd
*See note
See UI manual
8
DCD
*See note
See UI manual
20
DTR
*See note
See UI manual
15
Not used
RxD+ RxD(B)
See UI manual
17
Not used
RxD - RxD(A)
See UI manual
19
Not used
TxD+ TxD(B)
See UI manual
25
Not used
TxD - TxD(A)
See UI manual
*Note : All RS232 signals are present in RS422 mode.
The RocketPort interface box can only be used with the Rocket Port 550-8 and
RocketPort 550-16 (or the Universal 550 equivalents). These controllers have a single
DB25F mounted on the backplate which connects via the RocketPort cable to the
interface box. Alternatively the RocketPort 550-8 and 550-16 controllers (or the Universal
550 equivalents) may connect to the Comtrol Universal Interface (UI). Refer to the UI
manual for connector pin-outs.
The Quad, Octa, RJ11 and RJ45 RocketPort 550 versions do not support RS422 mode.
