36 - Embedded Diagnostic and Statistics Pages DeviceMaster Modbus Server User Guide: 2000535 Rev. C
Serial Interface Logs Page
Serial Interface Logs Page
The following page displays the serial message transmitted and received during
normal operation.
The format is as follows:
Pkt(N): ddd:hh:mm:ss.mss Rx/Tx:(data packet)
Where:
ddd Days since last system restart
hh Hours since last system restart
mm Minutes since last system restart
ss Seconds since last system restart
mss Milliseconds since last system restart
(data) Modbus/RTU message data.
Dropped RX Messages Due to
Invalid CRCs Number of messages from the application(s) that were dropped due
to an invalid Modbus/RTU CRC.
TX Byte Count (To Device) Number of bytes transmitted out the serial port.
Counter Name Description
