DeviceMaster Modbus Server User Guide: 2000535 Rev. C Embedded Web Pages - 27
Serial Interface Configuration Page
Serial Interface Configuration Page
The Serial Interface
Configuration page
provides:
• Links to the following
pages:
- Server
Configuration
(Main) Page (Page
26)
- Serial Interface
Communications
Statistics Page
(Page 34)
- Serial Interface
Logs Page (Page
36)
- Known Modbus/
RTU Device List
Web Page (Page 33)
for all ports or a
specific port.
Clicking the
Display Devices
(all) link or the
Display Devices for
a specific port.
• Access to the Edit Port
Configuration page for
each port (Port #)
• An overview of serial
device configuration
settings for each port,
which displays the
current settings
Note: The Application
TCP Connection
Status displays the
Remote
Connections.
Up to six active TCP/IP connections for each serial port may be displayed at
one time.
To change any settings for a port, select the corresponding Port # link, which opens
