DeviceMaster UP Modbus Server User Guide: 2000535 Rev. C
Installation Overview - 21
Configuring Port Redirector COM Ports
Configuring Port Redirector COM Ports
Use the following procedures to:
•
Add a DeviceMaster UP port
•
Configure the port for the secure port redirector
If necessary, refer to the secure port redirector help system for more information.
Adding a Secure
Port
Use the following procedure to add a secure port or ports.
Note: You must have enabled the security feature in SocketServer and have the IP
address and TCP port numbers and enabled the TCP Connection for each
port before performing the following procedure.
1.
If necessary, open the Secure Port Redirector, click Start, Programs, Secure Port
Redirector, and Secure Port Redirector.
2.
Click Port and Add.
3.
Select an available COM port in the
Virtual serial port drop list.
4.
Click Client or Server depending
on the COM port requirements.
5.
Enter the Remote IP address of the
DeviceMaster UP.
6.
Enter the TCP port number for
which you want to communicate on
the DeviceMaster UP.
7.
Click Ok.
8.
Repeat
for each port that you
want to use as a secure COM port.
