DeviceMaster Modbus Server User Guide: 2000535 Rev. C Embedded Diagnostic and Statistics Pages - 33
Embedded Diagnostic and Statistics
Pages
This section discusses embedded diagnostic and statistics web pages for Modbus
Server.
Known Modbus/RTU Device List Web Page
The Known Modbus/RTU Device List page provides device specific status and
statistics for each device on one or all ports.
Know Modbus/RTU Device List Page
Device ID Unit identifier associated with this device.
Active?
Status of device:
• Yes means that the last request received a valid
response and did not time out.
• No means that the last request timed out.
Tx Requests Number of Modbus messages transmitted to this device.
Rx Responses Number of Modbus responses received from this device.
Timeouts Number of response time-outs associated with this device.
Last Rsp Time The last response time from Modbus/RTU device.
Avg Rsp Time The average response time from Modbus/RTU device.
Min Rsp Time The minimum response time from Modbus/RTU device.
Max Rsp Time The maximum response time from Modbus/RTU device.
Invalid Responses Number of invalid responses received from this device.
