RocketPort® Serial Hub ia (RPSH-ia) Hardware Installation 10
Notices
The following table illustrates hardware specifications.
Notices
Radio Frequency
Interference (RFI)
(FCC 15.105) This equipment has been tested and found to comply with the limits for Class A
digital devices pursuant to Part 15 of the FCC Rules.
This equipment generates, uses, and can radiate radio frequency energy, and if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try and
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Labeling
Requirements (FCC
15.19) This equipment complies with part 15 of FCC rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that
may cause undesired operation.
Topic
Hardware
Specifications
Current consumption 180 mA (24VDC)
Input voltage 20 - 28VDC
Power consumption 2.8 W
Optional power supply:
Line frequency
Line voltage 50 - 60 Hz
100 - 240VAC
Ethernet host interface
10/100Base-T (10/100
Mbps - RJ45)
Hubs/server
OS dependent, see the
software documentation
Number of ports/hub 2
Baud rate/port (maximum) 115.2 Kbps
Driver control:
Data bits
Parity
Stop bits 7 or 8
Odd, Even, None
1 or 2
Dimensions 4.1” x 3.3” x 1.0”
Weight (hub, only) 10 oz
