Clippasafe 114 Deluxe Extendable, Dual Fix, No-Trip Gate - Manual (Page 4)

3
4
Mark the position for the wall fixings ‘C’ on one of the wall surfaces.
The hole for the lower wall fixings should be 26mm from the floor.
The hole for the upper wall fixings should be 691mm from the floor.
Fix the wall fixings ‘C’ using the appropriate fixings depending on the
surface available: wood screws for wooden surfaces, multi-use dowel and
concrete screws for concrete surfaces, multi-use dowel and cement screws
for cement surfaces, metal screws for metal surfaces.
These screws are not provided.
Insert the 4 screw adjusters ‘D’ and ‘E’ into the holes in the 4 corners
of the gate.
2 D 2 E
26 mm
691 mm
4 C
