7
8
If the metal in the viewer does not line up with the lines on the frame the
screw adjusters need to be adjusted. Open the latch and unscrew each of
the screw adjusters to increase the pressure.
clac
max 47 mm
min 22 mm
max 63 mm
min 18 mm
!
Continue to adjust the screw adjusters until the metal in the viewer lines
up with the lines on the frame when the gate is securely closed. Make
sure that the distance between the wall and the latch side of the frame is
no less than 22mm and no more than 47mm, and the distance between
the wall and the other side of the frame is no less than 18mm and no
more than 63mm.
