SPECIFICATIONS
Power supply 120V AC, 60 Hz
Power consumption 18W
External dimensions 17 X 3-5/8 X 12-1/2 inch (W x H x D), 430 x 92 x 318 mm (W x H x D)
Weight 11 lbs (5.0 kg)
Signal system Standard NTSC color television system
Recording System Rotary 2-head azimuth
Cassette VHS marked, 1/2 inch cassette tape
Tape speed SPA2 mode: 33.35mm/s, EPA6 mode: 11.12mm/s
Recording/playback time mode SP modes: A2, A12, A24, 24, 48, 72, 120, 168
EP modes: A6, A18, 30, 48, 72, 120, 168
Fast forward/rewind time Within 2 minutes (when T-120 is used)
Video input (BNC) I.OV(p-p), 75 Q. Unbalanced Luminance signal
Video output (BNC) 1 .OV(p-p), 75 ii Unbalanced Luminance signal
Horizontal resolution 350 lines (monochrome mode), 300 lines (color mode) (SPA2 mode)
Video S/N More than 45 dB: monochrome mode (SPA2 mode)
More than 45 dB: color mode (SPA2 mode)
Audio input Line input: 308mV (rms), more than 47k i2, pin jack
Microphone input: 0.245mV (rms), less than 5k Q, o3.5 jack
Audio output 388mV (rms), less than 4.7k П, pin jack
No. of audio tracks 1 track
Audio frequency characteristics 100 Hz to 10 kHz (SPA2 mode)
Audio S/N More than 43 dB (SPA2 mode)
Operating conditions Temperature: 41 °F to 104°F (5°C to 40°C)
Humidity: less than 80%
Storage conditions -4°F to 140“F (-20°C to 60°C)
Connector section
Alarm input Ground input: 0 to 0.5V
Alarm reset input Ground input: 0 to 0.5V
Alarm output DC 5V, impedance: 230 Q, less than 10mA
Recording trigger output During time lapse: 0/5V negative pulse signal
SPA2 and EPA6 mode: OV
Alarm recording: 0/5V (Programmable)
Except above-mentioned: 5V
Tape end output Open/Short, impedance: 220 Q, less than 20mA
External control input Ground input: 0 to 0.5V
Design and specifications are subject to change without notice.
Accessories
• Instruction manual
• Dew caution sheet
