The remote control unit provided with the receiver can also control KENWOOD cassette decks, CD player, and graphic equalizer
connected to the receiver through system control cords. For details of the controllable functions, refer to the instruction manuals
of these components.
TUNER operation keys
BAND Selects the broadcast band.
P.CALL Recalls preset stations.
CD player operation keys
DISC This key is used as the disc
selector of a multi-CD player.
Each press selects a differ
ent disc,
INPUT key
Selects the input sources.
TAPE 2 (MONITOR) key
Press to monitor the source being re
corded.
POWER key
MUTE key
Mutes the sound temporarily.
VOLUME keys
Adjust the listening volume. The VOL
UME CONTROL knob of the main unit
turns when these keys are operated.
^ WiA ^
C3 a
LÓ a
TJNEJl
BAND
m
ao_
TAPES
□ CD
a a
REC/APM ^ ■
a
CD
CD CD
“ ■ ►/!!
-a a a a
SURROUND
^DELAY^ ^R£AR^ CENTER
MULTILEVEL CONTROL
DISC
TAPE2
INPUT WONrTQRl
-dD Q
MUTE
CD
qp
VOLUME)
CD
IMNTHOL
C±)
J
KENWOOD
REMOTE CONTROL UNrr
RC-R0502
Cassette deck operation keys
These keys are used to operate TAPE
A and TAPE B decks.
REC/ARM key
When recording on TAPE B. puts the
deck in record-pause mode after leav
ing a non-recorded blank of 4 seconds.
Graphic equalizer operation keys
EFFECT Turns the graphic equalizer
ON and OFF.
M.CALL Recalls the preset equalizer
curves from memory.
SURROUND keys
SURROUND MODE
Switches the surround modes.
TEST TONE
Switches the test tone ON and OFF.
CENTER + MULTI LEVEL CONTROL
This combination adjusts the center
level,
REAR + MULTI LEVEL CONTROL
Adjusts the rear level.
DELAY + MULTI LEVEL CONTROL
Adjusts the delay time.
Model: RC-R0502
Infrared ray system
