PARTS LIST
Key Description =0:t
1 1 LEFT SIDE SHELF G523-1100-W1
2 1 FASCIA, LEFT SHELF G523-0051-W1
3 1 RIGHT SIDE SHELF G523-1200-W1
4 1 FASCIA, RIGHT SHELF G523-0052-W1
5 1 TOP LID G523-0100-W1
6 1 INNER INSERT, F/ TOP LID G523-0001-W1
7 1 TEMPERATURE GAUGE G518-0075-W1
8 1 BEZEL, F/ TEMPERATURE GAUGE G503-0002-W1
9 1 LOGO PLATE G523-0002-W1
10 1 HANDLE, F/ TOP LID G523-0003-W1
11 2 BEZEL, F/ LID HANDLE G509-0003-W1
12 2
RUBBER BUMPER, RECTANGLE, F/
TOP LID
G413-0025-W1
13 2 LID BUMPER, ROUND G501-0066-W1
14 1 HARDWARE F/ TOP LID ASSEMBLY G515-0035-W1
15 1 FIREBOX G523-3100-W1
16 3 MAIN BURNER G517-7300-W1
17 2
ELECTRODE, F/MAIN BURNER,
900MM WIRE
G515-0014-W1
18 2 FLAME CARRYOVER TUBE G524-0036-W1
19 1 SEAR BURNER G523-3200-W1
20 1 ROTISSERIE BURNER G614-1900-W1
21 1
RIGHT WIND SHIELD, ROTISSERIE
BURNER
G614-0052-W1A
22 1
LEFT WIND SHIELD, ROTISSERIE
BURNER
G614-0053-W1
23 1
ELECTRODE, F/MAIN BURNER,
600MM WIRE
G515-0067-W1
24 1 ELECTRODE, F/ ROTISSERIE G614-0094-W1
25 1 ELECTRODE WIRE, F/ ROTISSERIE G614-0059-W1A
26 1 GROUND WIRE, F/ El MODULE G614-0098-W1
27 1 BACK COVER, ROTISSERIE BURNER G523-0011-W1
28 1 LIGHT SWITCH G520-0013-W1
29 1 HALOGEN LIGHT ASSEMBLY G614-8200-W1
30 7 HOSE CLIP G608-0041-W1
31 1 SB EXTEND SHELF G523-3400-W1
32 1 SIDEBURNER PAN G523-0012-W1
33 1 ELECTRODE, F/ SIDEBURNER G430-2604-W1
34 1 LID, F/ SIDEBURNER G507-0011-W2
35 2 BUMPER, F/ SIDEBURNER LID G508-0033-W1
36 1 SIDEBURNER G523-0058-W1
37 1 SIDEBURNER GRATE G501-0077-W1
38 1 INNER PANEL, F/ CONTROL PANEL G523-0014-W1
39 1 HOSE VALVE REGULATOR G523-3700-W1
40 1 CONTROL PANEL G523-0020-W1
41 5 BEZEL, F/ CONTROL KNOB G614-0064-W1
42 1 BEZEL, F/ ROTISSERIE KNOB G614-0065-W1
43 1 IGNITER SWITCH MODULE G518-0026-W1A
44 1 REAR UPPER PANEL, FIREBOX G523-0013-W1
45 5 CONTROL KNOB G523-3800-W1
46 1 CONTROL KNOB, F/ ROTISSERIE G523-3900-W1
47 2 MATCH HOLDER AND CHAIN G508-0039-W1
Qty Description Part#
48 1 BOTTOM SHELF G523-0025-W1
49 2 DOOR MAGNET ASSEMBLY G501-0016-W2
50 1 TANK SHELF ASSY G523-4100-W1
51 1 LEFT SIDE PANEL G523-0800-W1
52 1 RIGHT SIDE PANEL G523-0900-W1
53 2 LOCKING CASTER G523-0028-W1
54 2 FIXED CASTER G523-0029-W1
55 1 ELECTRONIC IGNITION MODULE G513-0021-W1
56 1 ELECTRODE WIRE, F/ SIDEBURNER G606-0068-W1
57 1 LOWER BACK PANEL G523-0030-W1
58 1 GROMMET G501-0039-W1
59 1 12 VOLT ADAPTER G518-0076-W1
60 1 RIGHT PANEL F/ DRAWER G523-0031-W1
61 1 HEAT SHIELD, F/ TANK G523-1000-W1
62 1 FRONT BRACE G523-5000-W1
63 2 DRAWER FRONT G523-0034-W1
64 2 DRAWER FRAME G523-0035-W1
65 4 HANDLE, F/ DOOR & DRAWER G523-0036-W1
66 8 HANDLE END, F/ DOOR & DRAWER G509-0011-W1
67 1 DOOR, LEFT, NO HANDLE G523-0037-W1
68 1 BAG HOOK, F/ DOOR G523-0039-W1
69 1 CONDIMENT TRAY, LEFT DOOR G523-0040-W1
70 1 DOOR LINER, LEFT G523-0038-W1
71 1 DOOR, RIGHT, NO HANDLE G523-0041-W1
72 1
CONDIMENT TRAY, RIGHT DOOR,
UPPER
G523-0043-W1
73 1
CONDIMENT TRAY, RIGHT DOOR,
LOWER
G523-0044-W1
74 1 PAPER TOWEL HOLDER, DOOR G523-6300-W1
75 1 DOOR LINER, RIGHT G523-0042-W1
76 2 HEAT DIFFUSER, LONG G523-0048-W1
77 1 HEAT DIFFUSER, SHORT G523-0053-W1
78 4 COOKING GRATE, MAIN G523-0049-W1
79 1 WARMING RACK G523-0050-W1
80 1 GREASE TRAY G516-4600-W1A
81 1
CAP, F/ ELECTRONIC IGNITION
MODULE
G513-0021-W2
Not Pictured
Key Qty Description Part #
' HARDWARE PACK G523-B001-W1
1 ASSEMBLY MANUAL, ENGLISH G523-010801-W1
1 ASSEMBLY MANUAL, SPANISH G523-010802-W1
If you are missing hardware or have damaged parts after
unpacking grill, call 1-800-241-7548 for replacement.
To order replacement parts after using grill, call
1-800-4-MY-HOME®
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
464224211 • 13
