FRONT PANEL FACILITIES
OPERATION OF DECK I WITH A REMOTE
CONTROL UNIT NOT DESIGNED FOR
DOUBLE DECKS (System remote control)
Selecting DECK I
In order to operate DECK I with the remote control unit, adjust the
unit as follows: With the power off, press and hold the stop (■) but­
ton of DECK I, and turn the power on. Continue to hold the stop (■)
button for approximately five seconds. DECK I can now be operated
using the remote control unit, but DECK II cannot.
Switching to DECK II
To restore remote control operation to DECK II, press the stop (■)
button of DECK II while DECK II is in stop mode. DECK II can now
be operated using the remote control unit. Remote control opera­
tion can be switched back and forth between decks by pressing
the stop button of the desired DECK while it is in stop mode.
NOTE:
If a power failure or a sudden change in the power supply (caused by
lightning, etc.) occurs, the unit is reset to its original state. Only
DECK II can be operated by remote control. To restore operation to
either deck, repeat the above procedure from the beginning.
FUNCTION DISPLAY
G)
DECK I counter indicator
Normally the tape counter or time counter is displayed (see
page 10). It flashes for 4 seconds after the power cord is con­
nected to the power supply.
® DOLBY NR B/C indicator
(D AUTO indicator
This indicator lights when ALCA tuning is complete.
0
Level meter
Holds peak for about 1.3 seconds.
The mark beside the 0 dB mark indicates the Dolby NR sys­
tem standard level.
(D CD'DECK SYNCHRO indicator (CD SYNC)
This indicator lights steadily when the CD SYNC button is
pressed and the operation starts.
® DECK I tape transport mode indicators
See table entitled "TAPE TRANSPORTATION MODE INDICA­
TORS" on this page.
® FLEX indicator
This indicator lights when the FLEX button is pressed.
® Synchro copy indicator (COPY)
Indicator lights steadily ; Copying at normal speed.
Indicator flashes
: Copying at twice normal speed.
® AUTO BLE indicator
• See page 12.
DECK II counter indicator
Normally the tape counter or time counter is displayed (see
page 10). It flashes for 4 seconds after the power cord is con­
nected to the power supply.
(Q) DECK II tape transport mode indicators
See table entitled "TAPE TRANSPORTATION MODE INDICA­
TORS" on this page.
TAPE TRANSPORTATION MODE INDICATORS
These indicators display the current tape transport mode. The chart
below shows the meaning of each of these indicators. The indicators
for DECK I and DECK II differ only in the location of the PLAY and
REC indicators (DECK l-left, DECK ll-right).
For both DECK I and II Flashing rapidly
FonA/ard mode Reverse mode
Stop ►
Playback PLAY ^ PLAY
Fast forward
Fast reverse iM) ► ◄
Forward
music search
- PLAY
^ / 1 \
^f^PLAY -
'»1'' / 1 \ '^
Reverse
music search
K p LAY - ► ◄ - PLAY
/ / 1 \
s ' I
'
DECK II only CO Flashing slowly
Playback pause
Recording
Recording
standby
Recording
mute
Fowvard mode
PLAY
REC
Reverse mode
PLAY
M REC
REC
