FEATURES AND BENEFITS
m
z
Q
r
m X
KEY PARTS AND COMPONENTS
DETERGENT DISPENSER
There are four compartments, one each for prewash (not
used on this model) main wash, liquid bleach, and liquid
fabric softener.
0 CONTROL PANEL WITH LED DISPLAY
The easy-to-read LED display shows cycle options, settings
cycle status, and estimated time remaining during operation
NOTE: Sensors in the washer automatically detect the size
of the wash load to optimize washing time, based on the
selected cycle and options.
0 DIRECT-DRIVE MOTOR
The direct-drive motor provides improved performance
and reliability while increasing energy efficiency.
(Motor is not visible.)
0 LARGE-CAPACITY STAINLESS STEEL DRUM
The ultra-large stainless steel drum offers extreme
durability and is tilted to improve efficiency and allow
easier access for large items.
0 EASY-ACCESS LOCKING DOOR
The extra-large door locks during operation and has a
delay feature to prevent the door from being opened until
it is safe to do so.
0 FILTER ACCESS PANEL
Provides easy access to the drain pump filter, which
allows you to clean the filter or retrieve lost items without
a service call.
© LEVELING FEET
Four leveling feet (two in the front and two in the back)
adjust to improve washer stability on uneven floors. Feet
are adjusted and locked in place using the adjusting
wrench included with the washer.
Hot and Cold
Water Inlets
Power
Cord
Drain
Hose
Included Accessories
■
Hot and Cold
Water Hoses
Wrench (for removing
shipping bolts and
adjusting and
y^locking leveling feet)
Non-skid pads
Tie Strap
(for securing
drain hose
Caps (4)
(for covering
shipping bolt holes)
Elbow Bracket
(for securing
drain hose
Rear of Washer
Shipping Bolts/Retainers (4)
NOTE: Bolts/retainers MUST be removed prior
to operation. Keep for future use. See page 8.
Optional Accessories
Drain Hose Extension Stacking kit (For dryer)
2 d
C
jD
P/N 5215ER2002K D26 17002 (White)
D26 17008 (Ginger)
D26 17009 (Chili Pepper)
