— 26 —
d D
65~150
4 4 4 4
5.2 Printing Paper
Use the print paper shown in the following table or the paper with equivalent
quality.
Paper Type Product Name
Recommended thermal F230AA, P220AG, HP220A, HP220AB-1, P220AB, P220AE-1,
paper roll
PB670 (Red/Black), PB770 (Blue/Black) from Mitsubishi Paper
TF50KS-E2D from Nippon Paper
PD150R, PD160R from Ohji Paper
(Unit: mm)
CAUTION!
DO NOT use the following type of paper roll.
■ Paper with folds.
■ Paper with bent corners.
■ Paper pasted or glued to the core.
■ In-wound paper roll (print side in).
(Unit: mm)
5. OTHER
5.1 External Views and Dimensions
Paper width 112
Maximum print area 104 Maximum print area 82.5
φ
102 or less
Printing surface
Paper width 82.5 Paper width 80
Maximum print area 72
0
−1 0
−1 0
−1
Paper thickness (µm)* 65-75 75-150
Core inner diameter d (mm) φ12 φ25.4
Core outer diameter D (mm) φ18 φ32
*Thickness of label paper is the total of the
thickness of “liner sheet” and “label”.
