3-15
3.9.2 How to operate adjustable sensor
(1) Move the adjustable sensor unit to your required position by turning the
adjust-knob. First measure the position to detect, then align the mark of the
measure on the guide rail upper with the sensor position mark (yellow) on the
upper sensor to set to the position to detect.
The sensor movable range is shown below.
(2) Load the liner and close the guide rail upper and set voltage to 3V.
For voltage setting, see the chapter on Control Panel.
Sensor movable range
Left-side edge of paper
0 mm
118 mm (max. width of paper)
59 mm (sensor movable range)
