EX-TREME 330 3-D ARF
sharp hobby knife to cut through the balsa.
52. Position the two radio hatches in the radio
openings and temporarily hold in place with
masking tape. Drill a pilot hole in each corner,
through the plywood corner plates. Install the
two radio hatches with the 2mm x8mm screws
and a phillips screw driver. Tighten the screws
until the just contact the balsa, as to not crush it.
53. Install your spinner back plate, balanced prop,
and prop nut. Tighten it securely.
54. Install the spinner cone and tighten just snug.
55. Set the control throws initially to +/- 3/8” for all
surfaces. (After flight testing, adjust as needed.)
56. Set the cg to 5-1/4 to 5-3/4 from the leading
edge, measured at the fuse side. Keep the cg to
the front for the initial flights, then adjust as
needed.
57. Double check that all bolts are tight and use
locktite where needed, and double check the cg,
then charge your planes batteries.
58. Have fun.
