CAMCORP Fabricated Rotary Airlock - Manual (Page 9)

CAMCORP, INC.
9732 Pflumm Road Lenexa, Kansas 66215 Phone: 913-831-0740 Fax: 913-831-9271
www.camcorpinc.com
Section 5 – Part Lists & Component Information
Camcorp fabricated airlocks are designed to be durable and long lasting. When
you need replacement parts use the listing below that applies to your airlock. We
are not able to list all of the different configurations and drive options available for
each model so please consult the factory if you need this information. When
contacting the factory have the serial number plate information available. If you
need to adjust the RPM of your airlock please contact Camcorp to select the
proper drive components that are matched to the components in your system.
An exploded view drawing of the fabricated airlock is shown on page 5-5 for your
reference.
)4 -, + *% 9 % -* 3
)- ( (
4 : )4 -, 9 ;.) < & ( -,
1 Consult Factory 1 Housing Body
2 Consult Factory 2 End Plate
3 Consult Factory 1 Rotor
4 Consult Factory 1 Motor Mount / Tensioner Plate
5 Consult Factory 1 Chain Guard
6 Consult Factory 1 Chain Guard Cover
7 600002 6 Rubber Wiper
8 Consult Factory 1 Electric Motor*
9 600023 1 Gear Box
10 600001 2 4-Bolt Bearing
11 Consult Factory 1 Drive Sprocket*
12 Consult Factory 1 Drive Bushing*
13 Consult Factory 1 Driven Sprocket*
14 Consult Factory 1 Driven Bushing*
15 600031 1 Chain
* - Motor HP and Drive Components vary depending on the desired rotor RPM.
5-1
