CAMCORP Fabricated Rotary Airlock - Manual (Page 14)

CAMCORP, INC.
9732 Pflumm Road Lenexa, Kansas 66215 Phone: 913-831-0740 Fax: 913-831-9271
www.camcorpinc.com
)- +. -(
Dodge Tigear / Camcorp P/N 600023
Used on Models 8F(S/R)
Dodge Tigear / Camcorp P/N 600024
Used on Model 10F(S/R), 12F(S/R)
Dodge Tigear / Camcorp P/N 60030
Used on Model 10F(S/R)-S, 12F(S/R)-S, 16F(S/R), 20F(S/R),
24F(S/R)
Dodge Tigear / Camcorp P/N 600025
Used on Model 30F(S/R)
* - -(
Check your specific airlock. Motors sizes range from ½ HP to 5 HP.
2)6 )- 1(
Dodge 4-Bolt Flanged Bearing, 1 ½” - Used on Model 8F(S/R)
Dodge 4-Bolt Flanged Bearing, 1 15/16” – Used on Model 10F(S/R),
10F(S/R)-S, 12F(S/R), 12F(S/R)-S
Dodge 4-Bolt Flanged Bearing, 2 7/16” – Used on Model 16F(S/R),
20F(S/R), 24F(S/R)
Dodge 4-Bolt Flanged Bearing, 2 15/16” – Used on Model 30F(S/R)
,- 3 (> .(2 1(> 2)
Check your specific airlock drawing for the proper drive components and
drive RPM.
5-6
