CAMCORP Fabricated Rotary Airlock User Manual
Page 10
CAMCORP, INC.
9732 Pflumm Road Lenexa, Kansas 66215 Phone: 913-831-0740 Fax: 913-831-9271
www.camcorpinc.com
)4
-, + * =
9
=
) +
*)0 &-0
-* 3
)- (
(
4 :
)4
-,
9
;.)
<
& ( -,
1
Consult Factory
1
Housing Body
2
Consult Factory
2
End Plate
3
Consult Factory
1
Rotor / Rotor with Extended Shaft
4
Consult Factory
1
Motor Mount / Tensioner Plate
5
Consult Factory
1
Chain Guard
6
Consult Factory
1
Chain Guard Cover
7
600026
6
Rubber Wiper
8
Consult Factory
1
Electric Motor*
9
600024 / 60030
1
Gear Box / Gear Box for Slave Drive
10
600003
2
4-Bolt Bearing
11
Consult Factory
1
Drive Sprocket*
12
Consult Factory
1
Drive Bushing*
13
Consult Factory
1
Driven Sprocket*
14
Consult Factory
1
Driven Bushing*
15
Consult Factory
1
Chain
)4
-, + *
9
) +
*)0 &-0
-* 3
)- (
(
4 :
)4
-,
9
;.)
<
& ( -,
1
Consult Factory
1
Housing Body
2
Consult Factory
2
End Plate
3
Consult Factory
1
Rotor / Rotor with Extended Shaft
4
Consult Factory
1
Motor Mount / Tensioner Plate
5
Consult Factory
1
Chain Guard
6
Consult Factory
1
Chain Guard Cover
7
600005
6
Rubber Wiper
8
Consult Factory
1
Electric Motor*
9
600024 / 600030
1
Gear Box / Gear Box for Slave Drive
10
600003
2
4-Bolt Bearing
11
Consult Factory
1
Drive Sprocket*
12
Consult Factory
1
Drive Bushing*
13
Consult Factory
1
Driven Sprocket*
14
Consult Factory
1
Driven Bushing*
15
Consult Factory
1
Chain
* - Motor HP and Drive Components vary depending on the desired rotor RPM.
5-2
