CAMCORP Fabricated Rotary Airlock - Manual (Page 12)

CAMCORP, INC.
9732 Pflumm Road Lenexa, Kansas 66215 Phone: 913-831-0740 Fax: 913-831-9271
www.camcorpinc.com
)4 -, + * 9 -* 3
)- ( (
4 : )4 -, 9 ;.) < & ( -,
1 Consult Factory 1 Housing Body
2 Consult Factory 2 End Plate
3 Consult Factory 1 Rotor
4 Consult Factory 1 Motor Mount / Tensioner Plate
5 Consult Factory 1 Chain Guard
6 Consult Factory 1 Chain Guard Cover
7 600028 6 Rubber Wiper
8 Consult Factory 1 Electric Motor*
9 600030 1 Gear Box
10 600006 2 4-Bolt Bearing
11 Consult Factory 1 Drive Sprocket*
12 Consult Factory 1 Drive Bushing*
13 Consult Factory 1 Driven Sprocket*
14 Consult Factory 1 Driven Bushing*
15 600033 1 Chain
)4 -, + * = 9 = -* 3
)- ( (
4 : )4 -, 9 ;.) < & ( -,
1 Consult Factory 1 Housing Body
2 Consult Factory 2 End Plate
3 Consult Factory 1 Rotor
4 Consult Factory 1 Motor Mount / Tensioner Plate
5 Consult Factory 1 Chain Guard
6 Consult Factory 1 Chain Guard Cover
7 600029 6 Rubber Wiper
8 Consult Factory 1 Electric Motor*
9 600025 1 Gear Box
10 600022 2 4-Bolt Bearing
11 Consult Factory 1 Drive Sprocket*
12 Consult Factory 1 Drive Bushing*
13 Consult Factory 1 Driven Sprocket*
14 Consult Factory 1 Driven Bushing*
15 600033 1 Chain
* - Motor HP and Drive Components vary depending on the desired rotor RPM.
5-4
