YX-1024 Matrix Switching System—User Manual
2
1.0 Matrix System Overview
1.0.1 YX Matrix System
The YX-1024 Matrix switcher is a high performance switching equipment for audio/video
frequencies. It is used for multiple input/output cross switching of audio/video signals. It
provides independent YPbPr component and audio input/output terminals. Each YPbPr
component signal and audio signal is transmitted separately and switched separately, thereby
minimizing signal attenuation and ensuring high definition graphics and high fidelity signal
output.
The YX-1024 Matrix is used mainly in TV broadcasting projects, multi-media conference
halls, large display projects, TV teaching and command control centers.
Figure 1-1 YX-1024 Matrix
1.0.2 YX Matrix System Packing
YX-1024 Matrix Host
DC 12V/1.25A Adaptor
User Manual
Accessories Q’ty
Hanger 2pcs
Screw 6pcs
