Cutting depth adjustment

• Loosen the depth ac^uetment wing nut and

acquêt the cutting depth.

Ttghten the depth adjustment wing nut
eecurely atthe desired cutting deptii.

Depth ac^uetment wing nut

(S) Tighten

® Puli down

Fig. 6

Rip fence (EY3500B7727)

(Avaiiable as an accessory, not included)

• Rip fence is convenient for rip cuts and

repeated cuts of tmiform width.

Adjust rip fence as shown.

(S) Adjust

Rg.6

Alignment with cutting line

«Use the notch as a guide to estabfish

cutting position. Align the notch with
cutting Ine.
As the cutting position may differ

depending on the blade, do a trial cut

beforehand.

Fig. 7

■

—
