14 ADT Focus 200 Plus / Focus Cadet Control Panel Wiring and Programming Information
14.1 Typical EN4216MR Receiver Connection to ADT Focus 200 Plus / Focus Cadet Control Panel
EN4216MR Function EN4216MR
Terminal
Panel Terminal
Keypad Text
Power in (12V DC)
Vs
(19) + Aux Power
n/a
Ground
GND
(20) - Aux Power
n/a
Alarm 1
NC (1)
(25) Point 1
(user text)
(Follower)
Com 1
(26) Common
NO (1)
Alarm 2
NC (2)
(27) Point 2
(user text)
(Follower)
Com 2
(28) Common
NO (2)
Repeater AC Loss
NC (3)
(29) Point 3
RF Repeater AC
(Follower)
Com 3
(30) Common
NO (3)
RF Pt Low Battery
NC (4)
(32) Point 4
RF Pt Low Batt
(Latching)
Com 4
(31) Common
NO (4)
RF Pt Tamper
NC (5)
RF Pt Trouble
(Latching)
Com 5
(34) Common
NO (5)*
(33) Point 5
RF Pt Inactive
NC (6)
(35) Point 6
RF Pt Inactive
(Follower)
Com 6
(34) Common
NO (6)
Power Loss
POWER LOSS
(36) Point 7
RF Recvr Power
(Follower)
(37) n/a
Receiver Tamper
TAMP *
n/a
n/a
RF Jam
JAM
(38) Point 8
RF System Jammed
(Follower)
(37) n/a
* Point 5 is normally open to allow RF Pt Tamper and Receiver Tamper on one loop.
The end-of-line resistor must not be in series with the wire from terminal NO (5) to terminal 33. Add the following 2 connections to
terminate the combined loop:
1.
Connect a wire from TAMP terminal to NO (5) terminal.
2.
Connect a 2K-ohm resistor from TAMP terminal to COM 5 terminal.
