HI HLPRC03 SERIES LOAD POINT ASSEMBLY
Page 6
Step 9. Unpackage the load sensor and place the
Top and Bottom Load Sensor Housings on
the Load Sensor.
FIG. 7: LOAD SENSOR
Step 10. Apply a layer of grease to the O-rings inside
the loading cups and assemble cups with the
load sensor.
Step 11. Slide the load sensor assembly with cups
between the bottom and top plate into posi-
tion with the loading cups facing as shown.
FIG. 8: LOAD SENSOR
