Statusword, States (word 12 of input table), Mode (state) table – Hardy HI 1756-FC User Manual
Page 31: Integrated technician

VERSION
13
Firmware version
STATUS
14
Statusword (See Statusword below)
COUNTER
15
26
●
●
Chapter 4
Statusword
At word 14, the module returns a binary statusword where each bit indicates a state or
condition within the module. To interpret these states, note which bits are ON and use the
chart below to match each bit location to the state it represents.
For Example: If the statusword is 69 with a binary value of 0000 0000 0100 0101, bits 0,
2, and 6 are on. Bit 0 indicates an A/D conversion error, bit 2 indicates status is ON and
bit 6 indicates a shutdown error.
STATUSWORD bit positions refer to these variables:
Word
#
Definition
ERRORADCONVERT 0x0001/0
Millivolt return from the load cell
system is out of range for the unit.
ERRORADFAILURE
0x0002/1
Unit’s A/D converter not responding.
STATUS_ON
0x0004/2
System on or off
ERRORLOWALARM 0x0008/3
Low
alarm
ERRORHIGHALARM 0x0010/4
High
alarm
ERRORCONTROL_LOST
0x0020/5
Controller communication failure
ERROR_SHUTDOWN 0x0040/6
Shutdown
ERROR_RANGE
0x0080/7
Out of range value
ERROR_REC
0x0100/8
REC value over high limit
ERROR_RECMINUS
0x0200/9
REC value below low limit
ERROR_REFILL_OVER
0x0400/10 Exceed refill limit
STATUS_REFILL 0x0800/11
Refill
process
active
STATUS_BATCH_COMPLETE 0x1000/12 Batch
process
completed
ERROREEPROMWRITE 0x4000/14 EEPROM
Hardware
Error
STATUSCHANENABLED
0x8000/15 Set if channel is enabled
States (Word 12 of input table)
Mode (state) Table
Mode
Value Mode
Value
IDLE_MODE 0
RATE_CAL_MODE
7
AUTO_MODE 1
REFILL_MODE
8
MANUAL_MODE 2
FULL_MODE
9
START_MODE 3
MANUAL_HOLD_MODE
10
STOP_MODE 4
RATECAL_HOLD_MODE
11
SHUT_OFFMODE 5
INITIAL_REFILL_MODE
12
PAUSE_MODE
6
Integrated Technician
If there is NO IT JBOX, the instrument can still measure the sense voltage, the overall
load cell millivolts per volt, and the internal reference weight value. If the user has an IT
●
●
●
