 Step 4
Attach the tail rigging with the long and medium tabs to
the bottom of the fuselage using two #2 x 1/2-inch sheet
metal screws. The longest tabs go to the front, while the
medium length tabs go to the rear.
 Step 5
Carefully bend the remaining rigging tabs using pliers.
 Step 6
Attach the tabs to the top and bottom of the stabilizer
using four 4-40 x 1/2-inch socket head screws and four
4-40 lock nuts. Leave the bolts loose enough so the tabs
can be rotated.
Section 4: Stabilizer/Elevator Installation
