2| Product description

• Semi-hermetic eight-cylinder reciprocating compressor with suction-gas cooled drive motor.
• The stream of refrigerant sucked out of the evaporator flows over the motor and cools it
intensively. In this way, the motor can be kept at a relatively low temperature level, particularly
under high loads.

Fig. 1

2.1 Short description

Valve plate

Cylinder cover

Terminal box

Dimension and connection values can be found in Chapter 10

Transport eyelet

Discharge
shut-off valve

Oil pump

Oil sight glass

Drive section

Motor section

Suction

shut-off valve

Name plate
