5.2 Standard motor, design for direct or partial winding start
INFO A mechanical unloaded start with bypass solenoid valve is
not required.
Designation on the name plate Sticker on the terminal box
until A044 from A047 until A044 from A047
∆/YYY Y/YY
Y/YY
Compressors with this marking are suitable for direct or partial winding start. The motor winding is
subdivided into two parts:
Until type code A044: Part winding 1 = 60% and part winding 2 = 40%. This winding division
reduces the start-up current needed for a part winding start to approx. 65% of that for a direct start.
From type code A047: Part winding 1 = 50% and part winding 2 = 50%. This winding division
reduces the start-up current needed for a part winding start to approx. 50% of that for a direct start.
5| Electrical connection
