A-125
VC Phaser
System A - 100
doepfer
2
2. VC Phaser - Overview
Controls:
1
Level :
Attenuator to control the level of the
signal at input !
2
Shift :
Control for manually setting the
amount of phase shift
3
CV :
Attenuator for the phase shift voltage
control signal at input "
4
Res. :
Resonance control
5
Mix :
Control for setting the amount of the
original signal added to the phase-
shifted signal
In / Outputs:
!
Audio In :
Audio input
"
CV :
Input for pitch-shift voltage control
§
Audio Out : Audio output
A-125 VCP
CV
Shift
CV
Res.
Mix
Level
Audio In
➀
➁
➂
➃
➄
VC PHASE SHIFTER
0
10
0
10
0
10
0
10
0
10
Audio Out
