A-122, Vcf 3 - overview, Vcf 3 – Doepfer A-122 24dB Low Pass 2 User Manual
Page 2: Doepfer, Controls
A-105 / A-122
System A - 100
doepfer
2
2. VCF 3 - Overview
Controls:
1
Lev. :
Attenuator for audio input !
2
Frq. :
Cut-off frequency control
3
FCV :
Attenuator for filter CV at input §
4
QCV :
Attenuator for resonance CV at input
$
5
Res.:
Control for setting the filter’s reso-
nance (emphasis)
In / Outputs:
!
Audio In :
Input to the filter
"
FCV 1 :
Input for voltage control of the filter
cut-off frequency (1 V /octave)
§
FCV 2 :
ditto, level controlled by 3
$
QCV :
Input for voltage control of the filter’s
resonance; level controlled by 4
%
Audio Out : Output from the filter
A-122
VCF 3
FCV 1
FCV 2
QCV
Frq.
FCV
QCV
Res.
Lev.
Audio In
➀
➁
➂
➃
➄
24 dB Low Pass II
0
10
0
10
0
10
0
10
0
10
Audio Out
