DIAL ELECTRONIC
Connections
(4)
connectors for 16 rotary encoders
(ST1...ST16)
(5)
connector for the
switches / buttons
(JP1)
(7)
DIP switch
used to select one of
the presets
8 = uppermost switch
1 = lowest switch
(1)
power supply
7-12V / 100mA DC
(BU3)
(2)
Midi Out
(BU2)
(3)
Midi In
(BU1)
(6)
connector for the
LEDs
(JP2)
