User's Guide Page 11 DIAL ELECTRONIC
Extent of delivery
The DE delivery contains the following parts:
• Dial Electronic pc board, assembled and tested
• Power Supply (230V mains voltage, European type mains plug, output voltage
range 7...12V, current min. 100 mA) included only for shipments within Germany,
for shipments outside Germany please contact your local representative or dealer
• Dial Electronic user's guide (i.e. the guide in your hand)
• Pocket Dial user's guide
Rotary encoders, switches, LEDs and cables are not included but have to be added
by the customer. We offer a suitable control set (16 encoders with black knobs, 6
buttons, 4 LEDs, cables) that has to be purchased separately.
The DE control set contains the following parts:
• 16 rotary encoders (ALPS EC16B24)
• 16 black rotary knobs (same as used for Pocket Dial)
• 16 cable sets with female connectors for the encoders
• 6 momentary switches (round, with thread for mouting into a front panel)
• one 16 pin ribbon cable with 16 pin female connector, about 30 cm (for wiring the
switches to JP1)
• 4 LEDs (red, 3 mm)
• one 10 pin ribbon cable with 10 pin female connector, about 30 cm (for wiring the
LEDs to JP2)
Remark:
The measure of the 3 pin female connector of the cable sets is a little bit more than
the corresponding pin header on the pc board. Consequently the female connectors
have to be grinded off a bit (e.g. with sandpaper). Otherwise several female
connectors will not fit side by side.
