Checkline BM User Manual
Page 6
Electromatic Equipment Co., Inc
-6-
•
Industr. WC: for industrial chips of wood without barks and fines (similar P63)
and fresh wood chips P16 & P45 (which are not older than two weeks after
cutting down the tree).
If the weight of the filled 13 litre bucket is beyond 2,6 kg,
the standard wood chips calibration curves (2,4k resp. 2,0k) have to be used!
•
P100 chips: very coarse chips of wood according to class P100. Information:
P100 chips are bigger than G100 chips of wood! To avoid filling differences in
cause of these coarse chips make more measurements with one sample and
note the average!
Information: There is the possibility to add further existing calibration curves (e.g.
shredder, logging debris wood chips) to your BM2.
Definition of wood chips classes
The stated numbers refer to the particle size that goes through round gaps of the
corresponding diameters (e.g. P16 - 16 mm).
o
P16
minimum 80% of the bulk is between 3,15 and 16 mm
o
P45
minimum 80% of the bulk is between 3,15 and 45 mm
o
P63
minimum 80% of the bulk is between 3,15 and 63 mm
o
P100
minimum 80% of the bulk is between 3,15 and 100 mm
4.0
ACTIVATION OF THE “SUPER USER” FUNCTION
2 times
- Options – Unlock
Enter the 4-digit password by using the
button (standard is the 4-digit serial
number) and confirm by pressing the
button.
Electromatic Equipment Co., Inc
-11-
10.0 EXEMPTION FROM LIABILITY
For miss-readings and wrong measurements and of this resulting damage we refuse
any liability. This is a device for quick determination of moisture. The moisture
depends on multiple conditions and multiple materials. Therefore we recommend a
plausibility check of the measuring results. Each device includes a serial number
and the guarantee stamp. If those are broken, no claims for guarantee can be
made. In case of a faulty device, please contact Electromatic (www.checkline.com).
11.0 TECHNICAL DATA
Resolution of the display
0.5% water content
0.5°C temperature
Measuring range
5 up to 60% depending on the material
Operation temperature
0°C up to +40°C
Storage temperature
-20°C to +60°C
Temperature compensation
Automatically
Power supply
4 pcs. 1.5 Volt AA Alkaline batteries (900
measurements)
Auto Switch OFF
After app. 6 minutes
Current consumption
60mA (with light)
Display
128x64 matrix display, lighted
Dimensions
490 x 290 x 300 mm
Weight
App. 5.3 kg (including batteries)
Degree of protection
IP 40
Scope of supply
BM2, Measuring bucket 13 Litre
4 x 1.5Volt AA Alkaline Batteries
Software LogMemorizer
USB interface for PC transfer
USB cable
