Checkline DT-5TG User Manual
Electromatic, Features operational precautions, Dimensions (mm)

Instruction Manual
Panel Mount Tachometer
Model DT-5TG (VDC)
Features
Operational Precautions
!
If the unit is used in a caustic environment, we
suggest you use a NEMA 4X enclosure.
!
Keep unit free of vibration and shock.
!
When installing unit, keep power and sensor wires
separate. Tie cable shield to terminal E (earth ground).
!
After inserting wires, tighten terminal screws securely.
One of the most advanced on the market today, this
microprocessor-based panel tachometer not only mea-
sures rotational, linear and flow rate speeds, but can also
function as an elapsed time counter and ratio meter. By
choosing the desired input/output module(s), you can
design virtually any system imaginable.
!
Mounts easily — no brackets or screws or any other
hardware needed.
!
Tolerates a wide variation of voltages.
!
Immune to electrically noisy environments.
!
Programmable parameters and functions via front
panel membrane push-button switches.
!
Accepts a variety of input and output modules
!
No need to remember mathematical formulas.
!
Highly accurate.
!
Self-testing.
Dimensions (mm)
