2.0 O VERVIEW
2.1 Gauge
ON/OFF Switch
ZERO Key
LCD Display
Battery Compartment
(On rear)
STATISTICS Key
14
9.0 M EASURING L IMITS
Minimum Radius for Convex Surfaces 0.2" (5mm)
Minimum Radius for Concave Surfaces 2" (50mm)
Minimum Headroom 4" (100mm)
Minimum Sample Diameter 0.5" (13mm)
Minimum Substrate Thickness - F 20 mils (0.5mm)
Minimum Substrate Thickness - NFe 2 mils (50 µm)
