Model ESMH Motorized Test Stand
1
Thanks!
Thank you for purchasing a Mark-10 Model ESMH motorized test
stand. We are confident that you will get many years of great service
from this product.
Mark-10 test stands and load frames are ruggedly built for many years
of service in laboratory and industrial environments.
This User’s Guide provides unpacking, setup, and operator instructions,
along with specifications and dimensions. For additional information or
answers to your questions, our technical support and engineering
teams will be eager to help you.
Thank you again for your purchase and happy testing!
TABLE OF CONTENTS
INTRODUCTION .........................................................................2
UNPACKING ..............................................................................2
SAFETY TIPS..............................................................................3
SETUP.........................................................................................3
OPERATION ..............................................................................5
SPECIFICATIONS.......................................................................7
DIMENSIONS..............................................................................8
TEST STANDS BY MARK-10 .....................................................9
FORCE GAUGES BY MARK-10 ...............................................10
WARRANTY ..............................................................................10
10
User’s Guide
Force Gauges Series MG
• Low cost and small size
•
Aluminum housing is reversible for hand-held use or test stand
mounting
•
Peak memory for tensile and compressive loads
• Selectable units of measurement programmable auto shutoff
• Push-button calibration
•
IPM - Intelligent Power Management system for reliable op-
eration
WARRANTY
Mark-10 Corporation expressly warrants to its buyer for three (3) years from the
date of delivery that the goods sold are free from defects in workmanship and
materials. Mark-10 Corporation will, at its option, repair or replace or refund the
purchase price of goods found to be defective. This remedy shall be the buyer’s
sole and exclusive remedy. Any modification, abuse, exposure to corrosive envi-
ronment or use other than intended will void this warranty. This warranty is in lieu
of all other warranties, including implied warranties of merchantability and fitness
for an intended purpose. In no event shall Mark-10 Corporation be liable for any
incidental and consequential damages in connection with goods sold or any part
thereof.
FORCE GAUGES BY MARK-10
Force Gauges Series EG
•
Reversible aluminum housing for hand-held use or stand
mounting
•
Three units of measurement: lb, kg, N
• Programmable initial status of units and mode of operation
• Automatic peak memory
•
Push-button calibration
•
Battery or AC operation with programmable automatic shutoff
• Permanent configuration memory
• Optional RS-232, Mitutoyo and analog outputs
Force Gauges Series BG (in addition to EG features)
• RS-232, Mitutoyo and analog outputs
•
GCL – Gauge Control Language for full control of all functions
•
Automatic timed output on RS-232
• Dual set points with outputs
• General purpose I/O for external device control
•
Programmable analog and digital filters
•
Averaging mode for obtaining average force readings over
time
Capacities from 0.12 lb (0.5 N) to 1,000 lb (5,000 N)
