Carrier 40RU - Manual (Page 28)

28
Table 8C -- Fan Motor Data, Standard Motor — SI
UNIT
40RUA*07
40RUQ*07
40RUA*08
40RUQ*08
40RUS*08
40RUA*12
40RUQ*12
40RUS*12
40RUA*14
40RUS*14
40RUA*16
40RUQ*16
40RUS*16
208/230---1---60
Speed (r/s) 28.75 28.75 — — —
Shaft kW 0.97 1.79 — — —
Frame (NEMA) 56Y 56Y — — —
Shaft Dia (mm) 15.9 15.9 — — —
208/230---3---60 and 460---3---60
Speed (r/s) 28.75 28.75 28.75 28.75 28.75
Shaft kW 1.79 1.79 1.79 2.16 2.76
Frame (NEMA) 56Y 56Y 56Y 56Y 56Y
Shaft Dia (mm) 15.9 15.9 15.9 22.2 22.2
575---3---60
Speed (r/s) 28.75 28.75 28.75 28.75 28.75
Shaft kW 0.746 1.49 1.49 2.24 2.24
Frame (NEMA) 56 56HZ 56HZ 56HZ 56HZ
Shaft Dia (mm) 15.9 22.2 22.2 22.2 22.2
LEGEND
NEMA — National Electrical Manufacturers Association
Table 8D -- Fan Motor Data, Alternate Motor — SI
UNIT
40RUA*07
40RUQ0*7
40RUA*08
40RUQ*08
40RUS*08
40RUA*12
40RUQ*12
40RUS*12
40RUA*14
40RUS*14
40RUA*16
40RUQ*16
40RUS*16
208/230---1---60
Speed (r/s) 28.75 28.75 — — —
Shaft kW 1.79 1.79 — — —
Frame (NEMA) 56Y 56Y — — —
Shaft Dia (mm) 15.9 15.9 — — —
208/230---3---60 and 460---3---60
Speed (r/s) 28.75 28.75 28.75 28.75 29.08
Shaft kW 2.16 2.16 2.76 2.76 3.73
Frame (NEMA) 56Y 56Y Y56Y Y56Y S184T
Shaft Dia (mm) 22.2 22.2 22.2 22.2 28.6
575---3---60
Speed (r/s) 28.75 28.75 28.75 29.08 29.08
Shaft kW 1.49 2.24 2.24 3.73 3.73
Frame (NEMA) 56HZ 56HZ 56HZ 184T 184T
Shaft Dia (mm) 22.2 22.2 22.2 28.6 28.6
LEGEND
NEMA — National Electrical Manufacturers Association
40RU
