27
Table 8A -- Fan Motor Data, Standard Motor — English
UNIT
40RUA*07
40RUQ*07
40RUA*08
40RUQ*08
40RUS*08
40RUA*12
40RUQ*12
40RUS*12
40RUA*14
40RUS*14
40RUA*16
40RUQ*16
40RUS*16
208/230---1---60
Speed (rpm) 1725 1725 — — —
Hp 1.3 2.4 — — —
Frame (NEMA) 56Y 56Y — — —
Shaft Dia (in.) 5 /
8
5 /
8
— — —
208/230---3---60 and 460---3---60
Speed (rpm) 1725 1725 1725 1725 1725
Hp 2.4 2.4 2.4 2.9 3.7
Frame (NEMA) 56Y 56Y 56Y 56Y 56Y
Shaft Dia (in.) 5 /
8
5 /
8
5 /
8
7 /
8
7 /
8
575---3---60
Speed (rpm) 1725 1725 1725 1725 1725
Hp 1.0 2.0 2.0 3.0 3.0
Frame (NEMA) 56 56HZ 56HZ 56HZ 56HZ
Shaft Dia (in.) 5 /
8
7 /
8
7 /
8
7 /
8
7 /
8
LEGEND
NEMA — National Electrical Manufacturers Association
Table 8B -- Fan Motor Data, Alternate Motor — English
UNIT
40RUA*07
40RUQ*07
40RUA*08
40RUQ*08
40RUS*08
40RUA*12
40RUQ*12
40RUS*12
40RUA*14
40RUS*14
40RUA*16
40RUQ*16
40RUS*16
208/230---1---60
Speed (rpm) 1725 1725 — — —
Hp 2.4 2.4 — — —
Frame (NEMA) 56Y 56Y — — —
Shaft Dia (in.) 5 /
8
5 /
8
— — —
208/230---3---60 and 460---3---60
Speed (rpm) 1725 1725 1725 1725 1725
Hp 2.9 2.9 3.7 3.7 5.0
Frame (NEMA) 56Y 56Y Y56Y Y56Y S184T
Shaft Dia (in.) 7 /
8
7 /
8
7 /
8
7 /
8
1 1 /
8
575---3---60
Speed (rpm) 1725 1725 1725 1745 1745
Hp 2.0 3.0 3.0 5.0 5.0
Frame (NEMA) 56HZ 56HZ 56HZ 184T 184T
Shaft Dia (in.) 7 /
8
7 /
8
7 /
8
1 1 /
8
1 1 /
8
LEGEND
NEMA — National Electrical Manufacturers Association
