DWG 1002
REF DESCRIPTION (120V PLUG-IN) 1002 1003
NO. ITEM # ITEM # ITEM #
1 Painted Panel, Top 5944112 5944112 5944110
2 Heat Deflector, Top 5944047 5944047 5944045
3 Output Circuit Board Mount 5944090 5944090 5944090
4 Output Temperature Circuit Board 1041290 1041290 1041290
5 Core Thermocouple Sensor Assembly 1043014 1043014 1043014
6Damper Control Circuit Board 1159044 1159044 1159044
7 Upper Limit Switch (290 o F) 1012019 1012019 1012019
8 Damper Support 5944085 5944085 5944085
9 Damper Assembly 1043030 1043030 1043032
10 Damper Linkage 5944075 5944075 5944075
11 Damper Actuator Assembly 1043008 1043009 1043009
12 Painted Panel, Front 1040370 1040370 1040372
13 Terminal Block Mount 5944095 5944095 5944095
14 Terminal Block 1016017 1016017 1016017
15 Main Control Circuit Board Mount 5944100 5944100 5944100
16Brick Core Limit Switch (290 o F) 1012019 1012019 1012019
17 Brick 5903015 5903015 5903015
18 Galvanized Panel, Front 5944012 5944012 5944010
19 Insulation Panel, Front 1053030 1053030 1053032
20 Heating Element 1014110 1014120 1014130
21 Air Intake Grill 5944127 5944127 5944125
22 Heat Deflector, Bottom 5944052 5944052 5944050
23 Painted Panel, Left 5944120 5944120 5944120
24 Galvanized Panel, Left 5944000 5944000 5944000
25 Blanket Insulation, Side (Outer) 1050110 1050110 1050110
26Painted Panel, Back 5944017 5944017 5944015
27 Blanket Insulation, Side (Inner) 1050111 1050111 1050111
28 Aluminized Panel, Top (Inner) 5944042 5944042 5944040
29 1" Blanket Insulation, Top (Lower) 1050100 1050100 1050101
30 1" Blanket Insulation, Top (Upper) 1050102 1050102 1050103
31 1/2" Blanket Insulation, Top (Lower) 1050104 1050104 1050105
32 Aluminized Panel, Top (Outer) 5944032 5944032 5944030
33 Heat Deflector, Base (Back) 5944037 5944037 5944035
34 Galvanized Panel, Right 5944005 5944005 5944005
35 Painted Panel, Right 5944115 5944115 5944115
36Aluminized Panel, Right 5944055 5944055 5944055
37 Insulation Panel, Back 1053030 1053030 1053032
38 Aluminized Panel, Left 5944060 5944060 5944060
39 Brick Support Insulation, Back 1052050 1052050 N/A
" Brick Support Insulation, Right Back N/A N/A 1052051
" Brick Support Insulation, Left Back N/A N/A 1052061
40 Brick Support Insulation, Front 1052052 1052052 N/A
" Brick Support Insulation, Right Front N/A N/A 1052053
" Brick Support Insulation, Left Front N/A N/A 1052063
41 Brick Support Insulation, Right Side 1052054 1052054 1052054
" Brick Support Insulation, Left Side 1052064 1052064 1052064
42 Face Plate 1159032 1159032 1159032
43 Main Control Circuit Board Assembly 10430161043016 1043016
44 Element Saddle 5944070 5944070 5944070
45 Low Voltage Raceway 5944135 5944135 5944135
46Wall Mouting Hardware Kit 1190034 1190034 1190034
47 Air Discharge Grill 1040370 1040370 1040372
48 1/2" Blanket Insulation, Top (Upper) 10501061050106 1050107
Heater P Heater P Heater P Heater P Heater Par ar ar ar arts List ts List ts List ts List ts List
21
(Note: When ordering replacement parts, please include unit model number and serial number.)
