Heater Parts List
25
REF
NO. Description
2002 Plug-in
Item #
2002
Item #
2003
Item #
2004
Item #
2005
Item #
2006
Item #
1. Control Circuit Board Mounting Plate 5940308 5940308 5940308 5940308 5940308 5940308
2. Control Circuit Board Assy (Microprocessor) 1043012 1043012 1043012 1043012 1043012 1043012
3. *Blower Resistor (240VAC) 1017011 1017050 1017016 1017016 1017046 1017046
4. Face Plate 1159032 1159032 1159032 1159032 1159032 1159032
5. Brick Core Thermocouple (Sensor) 1043004 1043004 1043005 1043005 1043005 1043005
6. Room Temperature Sensor Mounting Panel 5949087 5949087 5949087 5949087 5949087 5949087
7. Built-in Room Temperature Sensor Assembly 1040360 1040360 1040362 1040362 1040362 1040362
8. Output Temperature Sensor Circuit Board 1040388 1040388 1040388 1040388 1040388 1040388
9. Painted Panel, Bottom 5943060 5943060 5943062 5943064 5943066 5943068
10. Grill Slats 5943100 5943100 5943102 5943104 5943106 5943108
11. Aluminized Air Channel, Left 5949028 5949028 5949028 5949028 5949028 5949028
12. *Heating Elements Contact factory with serial number of heater.
13. Heat Storage Brick 5903010 5903010 5903010 5903010 5903010 5903010
14. Galvanized Panel, Front 5943010 5943010 5943012 5943014 5943016 5943018
15. Grill Pin 5943099 5943099 5943099 5943099 5943099 5943099
16. Insulation Panel, Front 1053010 1053010 1053012 1053014 1053016 1053018
17. Painted Panel, Left 5943020 5943020 5943020 5943020 5943020 5943020
18. Painted Panel, Front 5943000 5943000 5943002 5943004 5943006 5943008
19. Painted Panel, Top 5943050 5943050 5943052 5943054 5943056 5943058
20. 1 ½” Blanket Insulation, Outer 1050073 1050073 1050074 1050075 1050076 1050077
21. 1 ½” Blanket Insulation, Inner 1050082 1050082 1050083 1050084 1050085 1050086
22. Aluminized Air Channel, Top 5949060 5949060 5949062 5949064 5949066 5949068
23. Insulation Panel, Back 1053010 1053010 1053012 1053014 1053016 1053018
24. Galvanized Panel, Right 5943040 5943040 5943040 5943040 5943040 5943040
25. Core Charging High Limit Guide Tube 1105016 1105016 1105018 1105020 1105022 1105024
26. Thermocouple Tube 5943222 5943222 5943220 5943220 5943220 5943220
27. Galvanized Panel, Back 5943070 5943070 5943072 5943074 5943076 5943078
28. Core Charging High Limit Switch 1040406 1040406 1040406 1040408 1040408 1040410
29. Outdoor Temperature Sensor, Optional 1302026 1302026 1302026 1302026 1302026 1302026
30. Terminal Block Kit 1040242 1040242 1040242 1040243 1040243 1040243
31. Low Voltage Raceway Cover 5943216 5943216 5943216 5943216 5943216 5943216
32. Painted Panel, Right 5943030 5943030 5943030 5943030 5943030 5943030
33. Terminal Block Mounting Bracket 5943212 5943212 5943212 5943212 5943212 5943212
34. Damper Assembly 1043010 1043010 1043010 1043010 1043010 1043010
35. Galvanized Plate, Bottom 5943080 5943080 5943082 5943084 5943086 5943088
36. Grill End Bracket, Right 5940998 5940998 5940998 5940998 5940998 5940998
“ Grill End Bracket, Left 5940996 5940996 5940996 5940996 5940996 5940996
37. *Blower Assembly (230VAC) 1021001 1021001 1021001 1021001 1021001 1021001
38. Damper Resistor Mount 5943226 5943226 5943226 5943226 5943226 5943226
39. Fan Mounting Spring 1159006 1159006 1159006 1159006 1159006 1159006
40. Damper Actuator Assembly 1043007 1043006 1043006 1043006 1043006 1043006
41. Damper Assembly Insulation N/A N/A N/A N/A N/A N/A
42. Base Cap Insulation 5943130 5943130 5943130 5943130 5943130 5943130
43. 1" Base Insulation 1050066 1050066 1050067 1050068 1050069 1050070
44. Element Push Nut 1151015 1151015 1151015 1151015 1151015 1151015
45. Remote Room Temperature Sensor (optional) 1302024 1302024 1302024 1302024 1302024 1302024
46. Grill Support Rail 5943024 5943024 5943024 5943024 5943024 5943024
47. Aluminized Air Channel, Right 5949026 5949026 5949026 5949026 5949026 5949026
48. Damper Circuit Board 1159044 1159044 1159044 1159044 1159044 1159044
49. Insulation Panel, Bottom 1053020 1053020 1053022 1053024 1053026 1053028
50. *Red Service Light (240VAC) 1015021 1015021 1015021 1015021 1015021 1015021
51. Security Base Shell 5942114 N/A N/A N/A N/A N/A
52. Security Base Filler 1190023 N/A N/A N/A N/A N/A
53. Wall Bracket Hardware Kit 1190032 1190032 1190032 1190032 1190032 1190032
54. Wall Support Bracket 5943200 5943200 5943202 5943204 5943206 5943208
55. Umbilical Cord N/A 1040600 1040600 1040602 1040602 1040602
56. Cord Connect 1015000 N/A N/A N/A N/A N/A
57. Galvanzied Base Tray 5943110 5943110 5943112 5943114 5943116 5943118
*Optional voltages or wattages are available. Contact factory with model number and serial number of the heater.
