Software Preparation
(first time only)
The following settings are necessary to prepare the DVD-ROM Drive Pack for use:
4WJn3ovii^r^nil : The following settings are unnecessary.)
1
Add the check mark for [DMA] in [Start] - [Settings] - [Control Panel] - [System]
- [Device Manager] - [CD-ROM] - [MATSHITA DVD-ROM SR-8173] - [Set­
tings].
2
Set [L:] for both [Start drive letter] and [End drive letter] in [Reserved drive
letters], then press [OK].
3
At the [System Properties], press [OK], The display will ask you to restart Win­
dows, select [Yes] to restart.
NOTE>
tWiïïaôwSÎÎSl (with the FIRSTAID CD included): When reinstalling, refer to the
above steps 2 ~ 3 to set the reserved drive letters of the CD-ROM drive.
When booting up from the FIRSTAID FD (for example, to reinstall the operating
system), the DVD-ROM Drive does not have to be replaced by the CD-ROM Drive
(CF-VCD271). The CD-ROM driver will recognize the DVD-ROM Drive.
Using the DVD-ROM Drive Pack in the MS-DOS mode
( i WflÏÏilîTi^Rfïïn : It is unnecessary to read this explanation.)
To use the DVD-ROM Drive Pack in the MS-DOS mode, configure the drive following the
steps below after performing the above steps I ~ 3. If the steps listed below are per­
formed without completing steps 1-3 above first, the drive will not operate properly.
1
Click the [Start] button then select [Shut Down].
2
Select [Restart in MS-DOS mode] and click [OK].
3
Open the "CONFIG.SYS" file for editing by issuing the following commands:
cd \ C Enter )
edit config.sys ( Enter )
4 Move the cursor to the line containing "CMtiT
delete the characters "rem" at the beginning of the line. (Deleting "rera" causes
the item to become valid.)
DEVICEH1GH=C:\WINDOWS\COMMAND\ATAPICD.SYS*/D:MSCDOOO
(If this line is missing, add it.)
*ATAP1CD.SYS %Windowsl98l : OAKCDROM.SYS
