Specifications
Item Description
Operating voltage range DC 5 V± 0.25 V
Drive 4x DVD-ROM Drive/24x CD-ROM Drive max.
speed
DVD
-ROM
Data Capacity 4.7 GB(DVD-5), 8.5 GB(DVD-9), 9.4 GB(DVD-IO)
Data transfer rate*' 44.32 Mbits/s (5,408 KB/sec) 4x speed (max.)
Access Time 280 ms (4x Speed, 1/3 Stroke*^)
Supports DVD-5, DVD-9, DVD-10, DVD-R*^
CD
-ROM
Data Capacity 656 MB
Data transfer rate*' 3600 KB/sec 24x speed (max.)
Access Time 190 ms (24x Speed, 1/3 Stroke*^)
Supports CD-Audio, CD-ROM, CD-R*", Photo CD, Video
CD, Enhanced Music CD, CD-RW*"
Cache memory 512 KB
Interface Conforms to enhanced IDE (ATAPI) standard
Dimensions (width x depth x height) 130 mm
X
150 mm x 23.7 mm
{5.1 "x5.9 "xO.9 ”}
Weight Approx. 400 g {0.88 lb.}
Operating temperature /
Humidity range
5 °C to 35 °C {41 “F to 95 “F | /30 % to 80 % RH
(no condensation)
*' If an unbalanced disc (i.e., a disc with which the balance has been displaced from the
center) is inserted, the speed may become slower if there are large vibrations while the
disc is rotating.
Stroke: Indicates the amount of movement the lens (pickup) of the DVD-ROM drive
must make in order to read data.
*3 3.95 GB only.
*“* Read only.
note
)------------------------------------------------------------------------------
• A PC Card is required to play DVD-Video or MPEG2 files.
•The region code has been set to the following :
Set to " 1 '.
Set to '2'.
Use of another region code or alteration of the region code invalidates the war­
ranty. For more information, please contact Panasonic Technical Support.
• If commercially available DVD playback software asks you the region code, set to
the following :
Set to ' 1
Set to "2".
