Attach the cover of the LCD Monitor

Attach the four screws.

5

Mount the LCD Monitor

Use these M4 screw holes to mount the LCD Monitor.

r

When installing the LCD monitor, locate the monitor under the dashboard as

shown in the figure to prevent the monitor from interrupting the sight of the

driver and to prevent the monitor from being hit by direct .sunlight.

Do not expose the computer to direct sunlight or excessive heat.
