(Auto Configuration)
Auto Configuration
Yes No
(Miscellaneous)
Miscellaneous
INIT NVRam
OSD Timeout
OSD Position
Phase adjustment is used to adjust the ADC sample pixel clock. A slider and the current
value are displayed. The adjustment range is 0 to 31, representing 0-360 degrees.
Adjust by pressing or ^ , then press [
2
). (If you want to cancel, press [T])
Clock adjustment is used to adjust the number of clocks per line (samples per line). A
slider and the current value are displayed. The range of clock adjustment is +/- 30
pixels from the VESA standard.
Adjust by pressing or , then press . (If you want to cancel, press [T])
Select [
2
], phase is adjusted automatically.
Auto Configuration automatically adjusts image position, clock, and phase. A confir
mation box is displayed to confirm the user selection. The default selection in the box
is “Yes”, highlighted by a green bar. If the “No” is selected, the main menu is re
opened and no changes are saved.
The Miscellaneous menu is used to select miscellaneous OSD setting and sub-menus.
Select the item by pressing or ^ , then press [
2
).
A confirmation box is displayed to confirm the user selection. The default selection is
“Yes”, and is highlighted by a green bar. If Q] is pressed, the previous menu is displayed.
OSD Timeout is used to set the OSD idle time-out. If no active action, key press or
automatic configuration occurs for the defined period, the OSD menu is closed. There
are four OSD time-out values available.
Seleet the item by pressing or ^ , then press .
The sub-menu is displayed.
Select the item by pressing or ^ , then press [
2
].
The sub-menu is displayed.
Adjust by pressing or ^ , then press . (If you want to cancel, press Q] )
□ (Information)
SYSTEM INFO
Version:
V-Freq-:
H-Freq-:
PixelCLK:
Width:
Height :
This menu is used to display information about the system. The OSD window is
displayed for 60 seconds after which control returns to main menu. If (T] is pressed,
the information window is closed and the main menu is displayed.
3
Press Q]
The OSD main menu disappears.
13
