Connect Tech BLUESTORM UNIVERSAL PCI CTIM-00015 User Manual
Page 18
BlueStorm Installation Guide, Connect Tech Inc.
18 Revision 0.08
Table 4: HDB-78 Pinouts for BlueStorm/SP (continued)
Pin
No.
Port
No.
RS-
232
Signal
Signal
Direction
RS-422/48
5
Signal
Signal
Direction
40
1
RTS
output
RTS A(-)
output
41
1
CTS
input
RTS B(+)
output
42
1
DSR
input
CTS A(-)
input
43
1
RI
input
CTS B(+)
input
44
1
SG
signal gnd.
SR
signal ref.
45
2
RTS
output
RTS A(-)
output
46
2
CTS
input
RTS B(+)
output
47
2
DSR
input
CTS A(-)
input
48
2
RI
input
CTS B(+)
input
49
3
RTS
output
RTS A(-)
output
50
3
CTS
input
RTS B(+)
output
51
3
DSR
input
CTS A(-)
input
52
3
RI
input
CTS B(+)
input
53
3
SG
signal gnd.
SR
signal ref.
54
4
RTS
output
RTS A(-)
output
55
4
CTS
input
RTS B(+)
output
56
4
DSR
input
CTS A(-)
input
57
4
RI
input
CTS B(+)
input
58
NC
no connect
NC
no connect
59
NC
no connect
NC
no connect
60
1
TxD
output
TxD A(-)
output
61
1
RxD
input
TxD B(+)
output
62
1
DTR
output
RxD A(-)
input
63
1
DCD
input
RxD B(+)
input
64
2
SG
signal gnd.
SR
signal ref.
65
2
TxD
output
TxD A(-)
output
66
2
RxD
input
TxD B(+)
output
67
2
DTR
output
RxD A(-)
input
68
2
DCD
input
RxD B(+)
input
69
3
TxD
output
TxD A(-)
output
70
3
RxD
input
TxD B(+)
output
71
3
DTR
output
RxD A(-)
input
72
3
DCD
input
RxD B(+)
input
73
4
SG
signal gnd.
SR
signal ref.
74
4
TxD
output
TxD A(-)
output
75
4
RxD
input
TxD B(+)
output
76
4
DTR
output
RxD A(-)
input
77
4
DCD
input
RxD B(+)
input
78
NC
no connect
NC
no connect
Cable CAG08FXDX and/or the IOBG08DB9V1 will send the signals to eight DB-9 male
connectors. See
for the DB-9 pinouts. Cable CAG08DB25 will send the signals to eight
DB-25 connectors. See
