Connect Tech BLUESTORM UNIVERSAL PCI CTIM-00015 - Manual (Page 15)

BlueStorm Installation Guide, Connect Tech Inc.
Revision 0.08 15
Table 3: VHDCI-68 Female Pinouts for BlueStorm/LP (8 port connector)
Pin
No. Port
No. RS-232
Signal Signal
Direction RS-422/485
Signal Signal
Direction
1 1 TXD output TXD- output
2 1 RI input CTS+ input
3 1 DCD input RXD+ input
4 1 DTR output RXD- input
5 1 RTS output RTS- output
6 1 DSR input CTS- input
7 1 RXD input TXD+ output
8 1 CTS input RTS+ output
9 2 TXD output TXD- output
10 2 RI input CTS+ input
11 2 DCD input RXD+ input
12 2 DTR output RXD- input
13 2 RTS output RTS- output
14 2 DSR input CTS- input
15 2 RXD input TXD+ output
16 2 CTS input RTS+ output
17 1, 2 SG signal gnd. SR signal ref.
18 3, 4 SG signal gnd. SR signal ref.
19 3 TXD output TXD- output
20 3 RI input CTS+ input
21 3 DCD input RXD+ input
22 3 DTR output RXD- input
23 3 RTS output RTS- output
24 3 DSR input CTS- input
25 3 RXD input TXD+ output
26 3 CTS input RTS+ output
27 4 TXD output TXD- output
28 4 RI input CTS+ input
29 4 DCD input RXD+ input
30 4 DTR output RXD- input
31 4 RTS output RTS- output
32 4 DSR input CTS- input
33 4 RXD input TXD+ output
34 4 CTS input RTS+ output
35 5 TXD output TXD- output
36 5 RI input CTS+ input
37 5 DCD input RXD+ input
38 5 DTR output RXD- input
39 5 RTS output RTS- output
40 5 DSR input CTS- input
41 5 RXD input TXD+ output
42 5 CTS input RTS+ output
43 6 TXD output TXD- output
44 6 RI input CTS+ input
45 6 DCD input RXD+ input
46 6 DTR output RXD- input
...Continued on next page
